Vivienda calle Pedro León Gallo número 413
Date
1984
Journal Title
Journal ISSN
Volume Title
Publisher
Universidad de Valparaíso
Authors
Abstract
La Casa tiene un sistema estructural de madera con entramado, anclado a muros laterales de hormigón armado con perfiles metálicos. La disposición simétrica de los elementos resistentes contribuye a la estabilidad estática, aunque presenta limitaciones ante otras demandas.
La obra gruesa se realizó con madera de roble y pino oregón, mientras que las terminaciones son de raulí y laurel. La elevación sur está revestida con laurel, con cuidadosos detalles en las uniones y ensamblajes para proteger la estructura del viento y la lluvia. La elevación norte, más expuesta, está revestida con paneles de fierro galvanizado acanalado.
The House has a wood frame structural system, anchored to reinforced concrete walls with metal profiles. The symmetrical arrangement of the load-bearing elements contributes to static stability, although it presents limitations to other demands. The rough work was carried out with oak and Oregon pine wood, while the finishes are made of raulí and laurel. The south elevation is clad with laurel, with careful details in the joints and assemblies to protect the structure from wind and rain. The north elevation, which is more exposed, is clad with corrugated galvanized steel panels.
The House has a wood frame structural system, anchored to reinforced concrete walls with metal profiles. The symmetrical arrangement of the load-bearing elements contributes to static stability, although it presents limitations to other demands. The rough work was carried out with oak and Oregon pine wood, while the finishes are made of raulí and laurel. The south elevation is clad with laurel, with careful details in the joints and assemblies to protect the structure from wind and rain. The north elevation, which is more exposed, is clad with corrugated galvanized steel panels.
Description
Plano no.13: elevación avenida Pedro León Gallo, escala 1:100. Plano no.9 A-B-C: planta tercer nivel y cubierta escala 1:50. Plano no.10-11A-11B-12A en 1 documento: planta estructura de cubierta y muros cortafuegos, escala 1.50. Plano no.12b: corte B-B, escala 1:50.
Keywords
Waisberg, Myriam, Casas históricas, Valparaíso
